MSI B650M GAMING PLUS WIFI Motherboard

Features:

• Chipset: AMD B650

• CPU Support: AMD Ryzen™ 7000 Series Desktop Processors (AM5 socket)

• Memory Support:

  • 4 × DDR5 DIMM slots, up to 192 GB total capacity

  • Supports DDR5 4800 / 5200 / 5600 / 6000+ MHz (by JEDEC & EXPO)

• Graphics Interface:

  • 1 × PCIe 4.0 x16 slot (reinforced with Steel Armor)

  • Integrated AMD Radeon™ Graphics (depending on CPU)

  • Display Outputs: 1 × HDMI 2.1, 1 × DisplayPort 1.4

• Storage:

  • 2 × M.2 slots (1 × PCIe 5.0 x4, 1 × PCIe 4.0 x4)

  • 4 × SATA 6 Gb/s ports

• Expansion Slots:

  • 1 × PCIe 4.0 x1 slot

• Audio: 7.1-channel HD Audio (Realtek ALC897 codec)

• Networking:

  • 1 × Realtek® 2.5G LAN

  • AMD Wi-Fi 6E & Bluetooth® 5.3

• USB Ports:

  • Rear I/O: 1 × USB 3.2 Gen 2x2 Type-C, 2 × USB 3.2 Gen 2, 4 × USB 2.0

  • Internal: Supports additional front-panel USB 3.2 Gen 1 and USB 2.0 headers

• Internal Connectors:

  • 1 × 24-pin ATX power connector

  • 1 × 8-pin CPU power connector

  • 3 × Fan headers

  • 2 × ARGB headers + 1 × RGB header

  • 1 × Front panel connector

• Form Factor: Micro-ATX (mATX)

• Dimensions: 243 × 244 mm

• Operating System Support: Windows® 10 / 11 (64-bit)

• Color: Black with red gaming accents

• Condition: Brand New
